ASP-134606-01
Board-to-Board Connectors
ASP-134606-01
ASP-134606-01 is replaced by WASPM-4X40H02.0LAKTR.It is interchangeable with ASP-134488, ASP-134486, ASP-134603, 4604, 184330, 184329, ASP-134602 and 88588-01.Operating Temperature
Connector Series: WASPM
Connector Pitch: 1.27mm
Rows: 4
$11 $8.5
In Stock (62999)
DownloadPDF Product message
Basic Information
Category Board-to-Board Connectors
Model ASP-134606-01
Connector Type Terminal
Connector Series WASPM
Connector Pitch 1.27mm
Terminal Interface Surface Mount (SMD)
Orientation Vertical
Material / Metal High Copper Alloy
Rows 4
Color Natural
Rated Voltage (VAC/VDC) 240
Rated Current per Contact (Max.) (A) Other
Plating Tin Plating (Sn)
Plating Thickness Other
Packaging Reel
Insulation Diameter (mm) Other
Wire Gauge (AWG) Other
Operating Temperature -55℃～125℃
Number of Circuits Other
Accessory Products

No accessories found.

Product Dimension
Dimension image will be displayed here
